2.1.1.3 SegmentRead
Read a data segment of the object initiated with the command «InitiateSegmentedRead».
Request Frame
OpCode BYTE 0x62
Len BYTE 1 (number of words)
Parameters
BYTE
[Bit 0]
[Bit 1…7]
ControlByte Toggle Bit
Not used
BYTE Dummy Byte without meaning
Response Frame
OpCode BYTE 0x00
Len BYTE 3…131 (number of words)
Parameters
DWORD “Communication Error Code Definition” on page 6-47
BYTE Length (max. 255 bytes)
BYTE
[Bit 0]
[Bit 1]
[Bit 2…7]
ControlByte Toggle Bit
Last Data Segment
Not used
BYTE [0…254] Data Bytes Read
BYTE Dummy Byte when length odd
