25
CAUTION
A ramp in retention position can trip you when stepping over
it. To prevent possible injury, get on the platform before putting
the ramp in retention position.
!
2. Continue to pull retention
ramp past the retention
position to ramp position
FIG. 25-1). Repeat for LH
ramp (FIG. 25-2).
RELEASING RETENTION RAMP
(TOP VIEW)
FIG. 25-2
NOTE: To unhook retention ramps, stand at side of the fl ipover of
the ramp that is to be unhooked. After the retention ramps
are unhooked, the recommended place for handling the
retention ramps is at the center of the free edges (FIG.
25-2).
LOCKING
ARM
RAMP
LH RAMP
RH RAMP
PULL
HERE
LOCKING
ARM
PULL
HERE
MOVING TO RETENTION POSITION
(RH SIDE SHOWN)
FIG. 25-1
