12 MAXPEEDINGRODS
OPERATION
INITIAL OIL FILL
BEFORE ADDING ENGINE OIL, REVIEW
SAFETY SECTION STARTING ON RAGE 5.
NOTICE
Engine oil must be added when the inverter is on
a flat, level surface, or an inaccurate reading
may result. Do not overfill. If the engine is
overfilled with oil, it can cause serious engine
damage.
1. Loosen the screw and remove the engine oil fill/
drain plug service panel to access the oil fill/
drain plug (see Figure 1)
Figure 1: Engine Service Panel
2. Clean the area around the oil fill/drain plug and
remove plug (See Figure 2).
Figure 2: Oil Fill/Drain Plug
3. Using the funnel and oil, pour the entire bottle of
oil into the engine (see Figure 3).
Figure 3: Oil Funnel
4. Do not overfill, if oil level is too high, oil will drain
out through the fill plug. See correct oil level in
Figure 4.
Figure 4: Engine Oil Correct Level
