POWERCORD
OPERATION
Using Extension Cords
MAXPEEDINGRODS Portable Power assumes no responsibility for the content within this table. The use of this
table is the responsibility of the user only. This table is intended for reference only. The results produced by
using this table are not guaranteed to be correct or applicable in all situations as the type and construction
of cords are highly variable. Always check with local regulations and a licensed electrician prior to installing
or connecting an electrical appliance.
Extension Cord Wire Gauge Size
LENGTH OF EXTENSION CORD (ft)
AMPS
5
10
15
20
25
30
35
10
20
18
16
14
12
12
10
20
18
16
14
12
12
10
10
30
16
14
12
12
10
10
8
40
14
12
12
10
10
8
8
50
12
12
10
10
8
8
6
60
12
10
10
8
8
6
6
80
10
10
8
8
6
6
6
100
10
8
8
6
6
6
6
120
8
8
6
6
6
6
6
DANGER
WARNING
Never connect the paralleling cord
to the inverters with the inverters
running. The inverters must not be
running and both the paralleling
cord switches must be off when
connecting the cords.
Do not attempt to parallel the
MAXPEEDINGRODS inverter with any
other manufacturers’ inverters.
Do not use the paralleling cord for
any application other than inverter
paralleling. Do not use this cord on
other manufacturers’ inverters.
Always ensure that both ends of
the paralleling cord are switched
off before connecting the inverters.
INVERTER PARALLELING OPERATION INVERTER PARALLELING OPERATION
1. Using only the MAXPEEDINGRODS paralleling cord
with both cord switches set to OFF (O), connect
one male plug to one inverter and connect the
remaining plug into the other inverter. Either of the
receptacles on the inverters can be used.
2. Start one of the inverters and wait until the output
ready light is on.
3. Turn both cord switches to ON ( I ).
4. Start the remaining inverter; wait until the output
ready light is on before connecting the load.
5. When power is present, a light will illuminate in the
three-prong plug that is plugged into the inverter.
6. To stop the inverters, unplug all connected loads,
turn both cord switches to OFF (O) and unplug the
cord on each inverter.
7. If during operation the inverters’ output is stopped
due to overloading, reduce the connected load by
unplugging appliances, and then push the reset
button and restart the inverter When the ready light
is on, the load can be reconnected.
