MAXPEEDINGRODS Q96 - RCA Connections; Back Camera Connection

PRODUCT OPERATION
02
PRODUCT OPERATION
02
07
08
*** If you use adapter to protect your original wire , you at least need to connect B+
battery ACC & GND to light the stereo
RCA：
We highly recommand you to use RCA cable to conncet to your amplifier
Rear Camera
Black: Ground-
Red: Reversing Light +12V
Rear Camera
Input
Back
connect to Universal back
camera Reversing Line
Back Camera connection
2-WAY CROSSOVER : SUB_R
3-WAY CROSSOVER : SUB_R
5.1: SUBWOOFER-R
SUBWOOFER
2-WAY CROSSOVER : SUB_L
3-WAY CROSSOVER : SUB_L
5.1: SUBWOOFER-L
SUBWOOFER
3-WAY CROSSOVER : FL
5.1: CENTER-L
BASS Speaker
2-WAY CROSSOVER : FL
3-WAY CROSSOVER : FL
5.1: RR
TREBLE Speaker
2-WAY CROSSOVER : FR
3-WAY CROSSOVER : FR
5.1: FR
TREBLE Speaker
2-WAY CROSSOVER : FL
3-WAY CROSSOVER : Fl
5.1: FL
2-WAY CROSSOVER : FR
3-WAY CROSSOVER : FR
5.1: RL
BASS Speaker
3-WAY CROSSOVER : FR
5.1: CENTER-R
AMP-C
Vedio Out
Your other screen
Vedio in
Your video device
Mic
Microphone
AUX-L
External MP3 audio
AUX-R
External MP3 audio
Original amplifier
Power Remote
BASS Speaker
ALTO Speaker
BASS Speaker
ALTO Speaker
