MAXPhotonics MFSC-1000X G4.0 Series User Manual

22
Chapter 4 Specification
2 -General Characteristic Parameters
No. Characteristics
Test
conditions
Min. Nom. Max. Unit
1
Operating Voltage
MFSC-1000X(G4.0)
200 220 240
VAC
Operating Voltage
MFSC-1500X(G4.0)
200 220 240
Operating Voltage
MFSC-1500X(G4.0) (optional)
360 380 440
2
Input Power
MFSC-1000X(G4.0)
100% Output 3.2
KW
Input Power
MFSC-1500X(G4.0)
100% Output 5.0
3
Operating Ambient
Temperature
10 40
℃
4
Operating Ambient
Relative Humidity
10 85 %
5 Cooling Method Water-cooling
6 Storage Temperature -10 60
℃
7 Dimensions 482.6*550*133 (W*D*H) mm
8
Weight MFSC-1000X(G4.0)
32±2
kg
Weight MFSC-1500X(G4.0)
36±2
3-Water Cooling Condition
No. Characteristics Min. Unit
1 Cooling Method Water Cooling
2
Ambient Temperature
≥ 30 ＜ 30 ℃
Chiller Set Temperature
Summer 26 Winter 22 ℃
3 Hydraulic pressure
≥3
bar
4
MFSC-1000X (G4.0) Water Flow Requirements 10
L/min
MFSC-1500X (G4.0) Water Flow Requirements 15
5
MFSC-1000X (G4.0) Chiller Rated Cooling
Capacity Requirements
2.5 kw
MFSC-1500X (G4.0) Chiller Rated Cooling
Capacity Requirements
3.5 kw
CAUTION :
◎
The Chiller needs to meet the requirements of the above table under the
conditions of a circulating temperature of 40 ° C and an outlet temperature of 26 ° C.
◎
The above recommended water pressure requires the pressure drop of the main
line Δp ≤ 0.5bar. If this value is exceeded, the main circuit water pressure should be
increased accordingly.
