PRODUCT SPECIFICATIONS
3 – 2
Physical Dimensions
1.028 max
[25.9 mm]
.25 ± .01
1.122 ± .02
[28.4 mm]
1.638 ± .005
[41.61 mm]
1.625 ± .02
4.000 ± .01
[101.6 mm]
1.75 ± .02
5.787 max
[146.6 mm]
6 x 6-32
UNC Tap
4 x 6-32
UNC Tap
4.00 ± .01
[102.1 mm]
3.75 ± .01
[95.25 mm]
Figure 3 - 1
Outline and Mounting Dimensions
RETEMARAPDRADNATSCIRTEM
thgieHhcni20.1sretemillim9.52
htgneLsehcni77.5sretemillim6.641
htdiWsehcni20.4sretemillim1.201
thgieWsdnuop3.1smargolik95.0
