DiamondMax 21 PATA Product Manual, Rev. A 5
Vibration, operating 5–22 Hz: 0.25 G, Limited displacement
22–350 Hz: 0.50 G
350–500 Hz:: 0.25 G
Vibration, nonoperating 5–22 Hz: 0.25 G, Limited displacement
22–350 Hz: 5.0 G
350–500 Hz:: 1.0 G
Drive acoustics, sound power (Bels)
Idle** 2.7 (typical)
3.0 (max)
Quiet seek 3.0 (typical)
3.4 (max)
Nonrecoverable read errors 1 per 10
14
bits read
Annualized Failure Rate (AFR) 0.34%
Warranty 3 years on distribution units.
To determine the warranty for a specific drive, use a web browser to
access the following web page:
www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. You will be
asked to provide the drive serial number, model number (or part num-
ber) and country of purchase. The system will display the warranty
information for your drive.
Contact start-stop cycles 50,000 at 25°C, 50% rel. humidity
Drive specification STM3320820A
