6 DiamondMax 21 PATA Product Manual, Rev. A
Table 2: Drive specifications summary for the 300 Gbyte model
Drive specification STM3300620A
Formatted Gbytes (512 bytes/sector)* 300
Guaranteed sectors 586,072,368
Heads 4
Discs 2
Bytes per sector 512
Default sectors per track 63
Default read/write heads 16
Default cylinders 16,383
Recording density 781 kbits/in max
Track density 145 ktracks/in avg.
Areal density 114.4 Gbits/in
2
avg
Spindle speed 7,200 RPM
Internal data transfer rate 1,030 Mbits/sec max)
Sustained data transfer rate OD 72 Mbytes/sec max
I/O data-transfer rate 100 Mbytes/sec max
ATA data-transfer modes supported PIO modes 0–4
Multiword DMA modes 0–2
Ultra DMA modes 0–5
Cache buffer 16 Mbytes
Height (max) 26.1 mm (1.028 inches)
Width (max) 101.6 mm (4.000 inches) +/- 0.010 inches
Length (max) 146.99 mm (5.787 inches)
Weight (max) 580 grams
Average latency 4.16 msec
Power-on to ready (max) 11 sec
Standby to ready (max) 15 sec
Track-to-track seek time (typical) <0.8 msec (read), <1.0 msec (write)
Average seek, read (typical) <11.0 msec
Average seek, write (typical) <12.0 msec
Startup current (typical) 12V (peak) 2.8 amps
Voltage tolerance (including noise) 5V ± 5%
12V ± 10%
Ambient temperature 0° to 60°C (operating)
–40° to 70°C (nonoperating)
Temperature gradient 20°C per hour max(operating)
30°C per hour max (nonoperating)
Relative humidity 5% to 90% (operating)
5% to 95% (nonoperating)
Relative humidity gradient 30% per hour max
Wet bulb temperature 37.7°C max (operating)
37.7°C max (nonoperating)
Altitude, operating –60.96 m to 3,048 m
(–200 ft. to 10,000+ ft.)
Altitude, nonoperating
(below mean sea level, max)
–60.96 m to 12,192 m
(–200 ft. to 40,000+ ft.)
Operational Shock 68 G at 2 msec
Non-Operational Shock 350 G at 2 msec
