DiamondMax 21 PATA Product Manual, Rev. A 7
Vibration, operating 5–22 Hz: 0.25 G, Limited displacement
22–350 Hz: 0.50 G
350–500 Hz:: 0.25 G
Vibration, nonoperating 5–22 Hz: 0.25 G, Limited displacement
22–350 Hz: 5.0 G
350–500 Hz:: 1.0 G
Drive acoustics, sound power (Bels)
Idle** 2.5 (typical)
2.8 (max)
Quiet seek 3.0 (typical)
3.1 (max)
Nonrecoverable read errors 1 per 10
14
bits read
Annualized Failure Rate (AFR) 0.34%
Warranty 3 years on distribution units.
To determine the warranty for a specific drive, use a web browser to
access the following web page:
www.seagate.com/support/service/
From this page, click on the “Verify Your Warranty” link. You will be
asked to provide the drive serial number, model number (or part
number) and country of purchase. The system will display the war-
ranty information for your drive.
Contact start-stop cycles 50,000 at 25°C, 50% rel. humidity
Drive specification STM3300620A
