Maxum 1900SR3 - Folding The Ski-Tow Tower

Chapter 7: Deck Equipment
53
Folding The Ski-Tow Tower
To fold the ski-tow
tower into the storage
position:
1. Remove the lower
lock-down bolt (A) on
each side of the tower.
2. Carefully fold the tower forward.
3. Replace the lower lock-down bolts (A).
4. Remove the upper lock-down bolts (B).
5. Lower the support legs (C).
6. Replace the upper lock-down bolts (B).
To return the tower to the towing position, perform the
above steps in reverse order.
PERSONAL INJURY and /or PRODUCT or PROPERTY DAMAGE HAZARD!
• Folding or unfolding the ski-tow tower is a two person task.
• Before each use of the folding ski-tow tower, make sure all four lock-down bolts are
tightened firmly.
• Read all warning labels on the ski-tow tower.
WARNING!
!
LOCK-DOWN BOLT
(TYPICAL, 4 - PLACES)
A
B
B
C
A
B
