Maxum 1900SR3 - Side Curtains Attachment

Chapter 7: Deck Equipment
59
Side Curtains (If Equipped)
1. Snap the forward
bottom snap (A)
of the side curtain
to the windshield
frame.
2. Snap the forward
top snap (B) to the
the covertible top.
3. Working your
way aft, snap
an upper snap
to the convertible
top, and then a
lower snap to the
windshield frame,
and so on until
complete.
A
B
NOTE:
PORT SIDE
SHOWN.
STARBOARD
SIDE TYPICAL.
