Chapter 9: Convertible Seats, Beds, & Tables
67
Cuddy Cabin to V-Berth Conversion (2100SC Only)
1. Place the forward filler cushion (A) over the
portable toilet (B).
2. Remove the aft cushions (C).
3. Lift the forward outboard
cushions (D) and slide the
filler boards (E) aft.
4. Align the velcro strips (F) on
the underside of the filler
boards with the velcro tabs
(G) on the aft support lip.
CA
B
D D
E
F
G
