Operating:
Average search time 30-60 seconds typical
Future proof with free software updates via a USB stick - see page 17
Low stream line profile, only 17cm in park position
Stores up to 15 satellites
Pre-programmed with 10 satellites including:
Astra variants 1-4
Hotbird 6/8/9
Power:
Powering: 12V operation
Power Consumption: Maximum 2A consumption during search
Standby Current: 0.2A
Battery Type: 2 x AA LR6 Alkaline Sealed (In Wireless Control Panel)
Fuse Type: 3A Mini Blade Automotive (In Control Box)
System:
Elevation Range: 10º to 70º
Azimuth Range: 380º
Skew Angle: ±45º
Operating Temp: -15º to 40º C
Safety System: Automatic lowering ignition
Cable Type: CAI approved 100 coaxial cable
UV Protection: All external plastic parts are UV stabilised
Testing: Fully weatherproof and watertight construction
System has passed extensive water ingress test
LNB:
Type: High Quality 0.2dB Universal Twin LNB
Output: Twin
Typical Gain: 65cm - 36dB 85cm - 38.1dB
Frequency Range: 10.7-12.75GHz
Arm Cable: RG179
Antenna:
Material: Aluminium
Reflector Thickness: 1mm
Finish: Powder coated with U.V. inhibited polyester-based
Outside Dims: 65cm dish: 67.0 x 71.5 cm 85cm dish: 85.0 x 90.5 cm
Reflecting Dims: 65cm dish: 63.0 x 67.5 cm 85cm dish: 81.5 x 87 cm
Mounting:
Plate Material: Aluminium
Fixing Method: Recommended adhesive(Sikaflex, Geocel or equivalent)
Fixing Studs: 6 x M5 studs for system removal
Cable Entry: Coaxial cable joining cover under antenna system
Wireless Control Panel:
Wireless Frequency: 868.3MHz
Wireless Range: 10m
Specifications:
Hellas Sat 2
Eurobird 9A
Thor 5-6Atlantic Bird 3
Hispat 1C/D
CE Declaration of Conformity
The Seeker Wireless Satellite Antenna has been designed, constructed and marketed in compliance
with safety requirements of EEC Directive 2006/95/EEC (Low voltage) and requirements of EMC
Directive 2004/108/EEC.
The wireless operation has been designed in accordance with CEPT-70.03.
