User Manual
EN
Double insulation
Diode
Dangerous voltage value!
description
This device is a compact digital padlock with 4 digit display
for measuring AC voltage, DC voltage, alternating current,
resistance, continuity diode and temperature. It is easy to
handle and due to its small size it can be always at hand
during a possible measurement.
general tecHnical paraMeters
Display 4 digits, LCD
maximum characteristic 6000
Overload display “1” appears on the LCD
Sampling About 3x in one second
Sensor
Padlock shaped for AC
measurement
Receiving width of jaws 27 mm
Max. Measurable
conductor
Ø 25 mm
Battery 1.5 V, 2 x AAA batteries
Low power indication
"BATTERY " symbol on the
display
Operating temperature
0 ºC - 40 ºC, <75%
humidity
Storage temperature
-20 ºC - 60 ºC, <85%
humidity
Dimensions 187 x 66 x 32 mm
Weight
approx. 150 g (including
battery)
Note: The conductor must
be in an area enclosed
between the measuring
jaws of the padlock for
accurate measurement
specification
Specication
Accuracy measurements were measured one year after
calibration at a temperature between 18 ºC and 28 ºC and
a relative humidity of <75%. Format: ± (% measured value
+ digit value)
ac voltage
Measuring range Resolution Accuracy
600 V 1 V ±(2,0%)
Overload
protection
DC 600 V AC
600V RMS
Input impedance 9 MΩ
Frequency 40 Hz - 400 Hz
Maximum input
voltage
600 V RMS
dc voltage
Measuring range Resolution Accuracy
600 V 1 V ±(1,8%)
Overload
protection
DC 600 V AC
600 V RMS
Input impedance 9 MΩ
Maximum input
voltage
600 V RMS
ac cUrrent
Measuring
range
Resolution Accuracy
2 A 1 mA ±(5,0% + 5)
20 A 10 mA ±(3,0% + 5)
200 A 100 mA ±(2,5% + 5)
400 A 100 mA ±(2,5% + 5)
600 A 1 A ±(2,5% + 5)
Response time
average,
calibrated for
the sine wave
of the RMS
Frequency
range
50 - 60 Hz
