WARNING DANGER
Never perform maintenance or assembly procedures with engine running or serious
personal injury may result.
1.Assemble straight pipe with swivel
（
D
）
flexible pipe
(
C).
2.Assemble flexible pipe(C)to elbow(A)on blower.
3.Assemble clamps(B)onto both ends of flexible pipe(C)and tighten.
4.Loosen wing nut(I
)
completely and expand open, stick handle clamp(J).
5.Align notches(H)in handle clamp with. pipe pegs(G)stick handle should be angled away from
operator.
6.Slide stick handle onto pipe with swivel(D).
7.Position stick handle for comfortable operation and tighten wing nut(I).
8.Assemble straight pipe(E)to pipe with swivel(D),turning straight pipe counter-clockwise to lock in
place.
9.Assemble straight pipe(F)to straight pipe(E)turning.
10. The way of installing is shown as diagram below. The accelerator controller is putted in spraying
a tube
Install Blower Pipes /Stick Handle
-10-
