Installation
- 11 -
3.1 Mechanical installation
DANGER
Select an appropriate installation location for the instrument.
Plan out the mechanical mount·before positioning poles or drilling holes. Make sure
the mount has a sufficient bearing capacity. The dowels must be selected and
authorized according to the condition of the wall.
The manufacturer shall accept no liability if the instrument is installed incorrectly.
Plan how to lay cables and tubes and their path in advance. Lay the hoses, data cables
and power cables without any bends so that they do not pose a tripping risk.
Remark:
For information on installation with optional accessories, refer to the
relevant installation instructions.
3.1.1 Required tools
Figure 4 Required tools
