Maxx SP5 B - Rinsing Water Connection and Drain (SP5 S-F;SP5 S-A)

Installation
- 28 -
3.3.2.5 Rinsing water connection and drain (SP5 S-F/SP5 S-A)
Hose nozzle : ¾“
tube Ø (internal) 25 mm
Rinsing water connection and drain (SP5 S-F)
Schlauch: Ø (internal) 25 mm hose nozzle: ¾“
Figure 36 Rinsing water connection and drain (SP5 S-A)
