Contents
01
• Bypass charging function: when the unit is off, it can be activated a with bypass output
and can continue to charge the battery.
• High charging current: the maximum charging current can be 200A for the OG-10KMAX,
180A for the OG-7.5KMAX, and 170A for the OG-5KMAX.
• Wide range of AC input voltage: AC input range of 90-280V. This wide range makes it ideal for
generator applications
• Grid or battery priority option: Grid or Battery priority option is available.
• Battery Charging Program: Complete control over the battery charging profile is available. The maximum
voltage, float voltage and low voltage point can all be manually set.
• 50/60HZ compatible
• Intelligent: Intelligent adjustment of over-discharge, voltage, intelligent fine-tuning of intelligent cooling fan,
intelligent adjustment of speed according to power and charging current and core
temperature inside the machine
• Safety: Inverter charger is built with safety as the first priority. Comprehensive protection, such as
over-charge protection/over-discharge protection/overload protection/output short-circuit protection/
over-temperature protection, etc. Transformer over-temperature protection
is a leading design in the industry. Wide range of AC input voltage: AC input range of 90-280V. This wide
range makes it ideal for generator applications
Grid or battery priority option: Grid or Battery priority option is available.
Features
Features……………………………………………………………………… 01
Diagram…………………………………………………………………………02
Specification……………………………………………… ……………03/04
Front panel……………………………………………………………………05
LCD Display icons…………………………………………………………06/07
LCD Setting ……………………………………………………………………08/11
Display Information …………………………………………………………12/13
Fault Code Table ……………………………………………………………14
Warning Code Table ………………………………………………………15
