Display Information
The LCD information can be switched by pressing “Scroll” key. The selectable information
is switched as below order: input voltage/frequency, battery voltage, charging current, output
voltage/frequency, load percent, load in Watt, load in VA, load in Watt, main CPU Version.
Input voltage/Output voltage
Utility voltage is 220V, output voltage is 220V
Input frequency
Utility frequency is 50.0Hz
Battery voltage
Battery voltage is 50.0V
PV voltage
PV voltage is 50V
Charging current
Charging current is 40A
CHARGING
PV power
PV power is 2KW
(for PWM / MPPT Charge Controller)
Output frequency
Output frequency is 50Hz
Load percentage
Load percent is 80%
Load in VA
The load is 3.0KVA
Load in Watt
The load is 3.0KW.
CPU software version
CPU software version 108
PWM Charge Controller software version
CPU software version 1.00
PWM Charge Controller software version
（for PWM Charge Controller Build-in）
12 13
(for PWM / MPPT Charge Controller)
