14
This training device is equipped with a folding slide frame. This allows the
footprint of the device to be reduced when stored away.
Folding up, securing and folding down of the slide frame must be carried out
carefully by an adult. Be sure to check that the sliding frame is secure in both
the up and down positions.
CAUTION
Never train if the slide frame is not tight and secure.
Folding Mechanism
1. Attaching the tethering straps
Put the loops of the two straps (F02) around the right- and left-hand
grips of the xed handlebar.
2. Loosen and remove the safety knob
Loosen and remove the safety knob (C32) by turning it anti-clockwise
and pulling it out.
3. Lift and secure pedal arms
Raise the right pedal arm from the rear end of the tread so you can
secure the eyelet at the end of the tread to the snap hook on the right
strap. Here you must move the pedal arm on the drive wheel into the
appropriate position. Repeat with the left pedal arm.
4. Lift and secure the slide frame
Lift the slide frame until the securing hole of the slide frame matches the
hole on the folding frame. Then insert the safety knob again and tighten
it clockwise.
