Maxxus CX 4.3F User Manual

31
ENG
Part No. Description Qty
A01 Main Frame 1
A02 Upright Post 1
A03 Handrail Arm /L 1
A04 Handrail Arm /R 1
A05 Foot Pedal Tube /L 1
A06 Foot Pedal Tube /R 1
A07 Rotate Bar /L 1
A08 Rotate Bar /R 1
A09 Idle Wheel Bracket 1
A10 Belt Pulley Shaft 1
A11 Crank /L 1
A12 Crank /R 1
A13 Guide Rail 1
A14 Handrail /L 1
A15 Handrail /R 1
A16 Stationary Handlebar 1
A17 Front Stabilizer 1
A18 Adjustable Disk 2
A19 Rotate Bar Connect Bracket 2
A20 U Shape Bracket 2
B01 Bolt 1/4'' 2
B02 Washer 1/4'' 4
B03 Nylon Nut 1/4'' 2
B04 Nut M10 (6.0T) 1
B05 Nut M10 (8.0T) 1
B06 C-ring 20 1
B07 Wave Washer M21 2
B08 Washer M20 1
B09 Rotate Bar Wheel Spacer 2
B10 Bolt M8 1
B11 Bolt M10 1
B12 Screw M3.5 2
B13 Bolt M8 6
B14 Screw M8 4
B15 Bolt M5 2
B16 Washer 1/2" 2
B17 Screw M5 4
B18 Shaft ∅19 2
B19 Spacer 2
B20 Nylon Nut M12 2
B21 Screw M5 22
B22 Bolt M12 2
Part No. Description Qty
B23 Screw M6 8
B24 Nut M20 2
B25 Nut M8 1
B26 Nylon Nut M10 1
B27 C-ring .17 1
B28 Bolt M8 4
B29 Nylon Nut M8 8
B30 Curve Washer M8 10
B31 Handrail Arm Axle 2
B32 Bolt M8 4
B33 Spring Washer M20 2
B34 Bolt M10 2
B35 Bolt M8 4
B36 Bolt M6 4
B37 Washer 5/16" 4
B38 Bolt M8 2
B39 Screw M4 6
B40 Screw M8 2
B41 Bolt 3/8'' 2
B42 Washer 3/8'' 4
B43 Dome Nut 3/8'' 2
B44 Spring 1
B45 C-ring 20 2
B46 Washer 5/16" 4
B47 Bolt M8 2
B48 Bolt M8 2
B49 Bushing Spacer 4
B50 Screw M6 4
B51 Shaft Housing 4
B52 C-ring 35 2
B53 Washer 5/16 4
B54 Bolt M8 2
B55 Nut M20 2
B56 Washer M20 2
B57 Knob /L 1
B58 Knob /R 1
B59 Screw M5 1
B60 Bolt M5 1
B61 Nut M5 1
B62 Screw M6 1
B63 Fixed Plate /1 1
B64 Fixed Plate /2 1
Spare Parts List
