Part No. Description Qty
B65 Guide Pin 1
C01 Main Cover /R 1
C02 Main Cover /L 1
C03L Disc Cover /L 1
C03R Disc Cover /R 1
C04 Oval End Cap 50x100 2
C05 Adjustable Foot Pad 6
C06 Transport Wheel 2
C07 Upright Post Decorative Cover /L 1
C08 Upright Post Decorative Cover /R 1
C09 Oval End Cap 30x70 4
C10 Belt 1
C11 Nut Cap M8 4
C12 Foot Pedal 2
C13 Foam Grip 2
C14 Round End Cap .1-1/4" 2
C15 Foam Grip 2
C16 Water Bottle Holder 1
C17 Handrail Arm Decorative Cover -A 2
C18 Handrail Arm Decorative Cover -B 2
C19 Belt Pulley 1
C20 Rotate Bar Wheel 2
C21 End Cap .101.6 4
C22 MOS Washer 4
Part No. Description Qty
C23 Bushing O33.4 4
C24 Washer .14 4
C25 Safety Knob 1
C26 Handrail End Cap 2
C27 Square End Cap 20x40 2
C28 Spacer /L 1
C29 Spacer /R 1
C30 End Cap for Pedal 8
D01 Hand Pulse Sensor 1
Set
D02 Computer 1
D03 Flywheel 1
D04 Cable 1 1
D05 Cable 2 1
D06 Motor with Cable 1
D07 Sensor with Cable 1
D08 AC Adapter 1
D09 AC Plug Cable 1
D10 Motor Tension Cable 1
E01 Bearing 6004 14
E02 Bearing 6003 8
E03 Bearing 6001 4
F01 Aluminum Guide Rail 2
F02 Ribbon & Hook 2
Set
Spare Parts List
