Parts List – Multipress
Assembly – Multipress
Part Description Qty
71 Hex. Head Screw M10x75 2
72 Hook 2
73 Carabiner Hook 3
74 Pull Bar, long 1
75 Pull Grip 2
77 Dumbbell Bar Holder, xed 1
78 Dumbbell Bar Holder, moving 1
80 Shelf, long 2
81 Mounting for Leg Stabiliser 1
82 Leg Holster w. Curved Cushion 1
83 Threaded Spring Clip Grip 1
84 Locking Pin Ø10x100 1
85 Roller Guide 1
86 Foot, rear 1
87 Spring plate Ø12 6
90 Basic Pipe f. Barbell Bar 1
Carefully unpack all delivered parts. Have someone there to help you as some of the training device parts are bulky and
heavy.
Check that all the parts and xing materials (screws, nuts, etc.) have been delivered.
Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of assembly are not
covered by the warranty or guarantee. Therefore, read through the assembly instructions carefully before you start assem-
bling, follow each assembly step exactly as described and keep to the correct sequence of assembly as instructed.
Assembly of the training device must be carried out thoroughly by an adult person only.
Assemble the training device in a location which is level, clean and clear of obstructions. 2 people are required to carry out
the assembly.
Please be aware a possible risk of injury at the time of assembly and at each time of using this device exists. For this rea-
son, always be careful and thorough in your actions when assembling this device.
Make sure that the parts necessary for each stage of assembly are only hand tightened together and only tighten parts
completely when all parts have been tted together perfectly.
Training can only start when the training device has been fully assembled.
To Next Page
