29
17
19
32
31
19
16
32
39
ENG
Assembly Step 7
Attach back rest cushion (29) to the back-rest support tube (17) using four hexagonal screws M8x20 (19) and four washers
Ø8 (32)
Assembly – Training Bench
Assembly Step 8
Attach the seat cushion (31) to the sliding carriage (16) using four hexagonal screws M8x20 (19) and four washers Ø8 (32).
