41
9
38
9
10
6
Scope of Delivery – Multipress
Traction Cable (39) - Length 4.430 mm
Traction Cable (42) - Length 1.860 mm
2x Traction Cable (47) - Length 2.380 mm
2x Traction Cable (58) - Length 3.580 mm
Traction Cable (59) - Length 10.690 mm
Note:
When assembling the rollers (38) only tighten the screws so far
that they are turned into the nut.
Do not over-tighten the screws as this may cause the rollers to
block.
Part Description Size Qty
9 Washers Ø10 50
10 Safety Nut M10 25
38 Roller Ø95 x Ø10,5 25
41 Socket Head Screw M10 x 45 25
