Assembly – Training Bench
Part Description Type Quantity
1 Base Bar, front 1
2 Base Bar, rear 1
3 Base Bar 1
4 Mounting Plate, bent T3,0x59x140 1
5 Hexagonal Head Screw M10x100 2
6 Hexagonal Head Screw M10x75 2
7 Mounting Plate, straight T4,0x50x140mm 1
9 Grip Screw with Locking Pin M18x1.5mm 2
16 Sliding Carriage
17 Support Tube for Back-Rest 1
18 Base Frame for Seat Cushion 1
19 Hexagonal Head Screw M8x20 12
20 Guide Pipe 2
21 Aluminium Cap, round Ø50xØ11x9,5mm 4
29 Back-Rest Cushion 840x330x50mm 1
30 Distance Tube Ø16x50mm 2
31 Seat Cushion 370x300x50mm 1
32 Washer Ø8 14
33 Washer Ø10 10
34 Shaft Pipe for Arm Curler 1
35 Swivel Bracket for Leg Curler 1
36 Swivel Bracket for Arm Curler 1
37 Cross Pipe Ø25xT2,0x450 3
38 Safety Split Pin Ø10x85 1
39 Hexagonal Head Screw M10x20 2
40 Cushion for Arm Curler 1
42 Distance Tube Ø25x67 1
47 Round Cushion 6
48 Cover Plate (large opening) 6
49 Cover Plate (small opening) 6
50 Hexagonal Head Screw M8x25 6
51 Stand Pipe 1
52 Safety Nut M10 4
53 Safety Nut M12 2
54 Washer Ø12 4
55 Hexagonal Head Screw M12x75 2
56 Headless Screw M10x20 4
59 Safety Split Pin Ø10x100 1
60 Hexagonal Head Screw M8x25 2
