Warranty
The ARC is warranted against material and
workmanship defects for a period of 10 years from
the date of purchase. Mayflower Electronics may
elect to repair or replace this product at their
option. Retain your invoice or order number as
proof of purchase and provide your order number
in any warranty communication to Mayflower
Electronics.
This warranty is only in effect if product is
purchased directly from Mayflower Electronics or
from an authorized retailer. Warranty is not valid if
serial number has been removed or otherwise
altered.
Cosmetic damage is not covered during the
warranty period. Opening the case or making
other modifications will also void the warranty.
ARC Owner’s Manual rev 1.0
Mayflower Electronics
2413 Riverfront Center
Amsterdam, NY 12010
518-866-4605
CustomerService@MayflowerElectronics.com
Specifications
• Frequency Response: +/-0.05 dB (20Hz-20kHz)
• THD 1 Khz 150 Ohms: 0.0026%
• IMD CCIF 15 Ohms: 0.0007%
• IMD SMPTE: 0.001%
• Noise 24/96 (A Weighted): -109 dBu
• Max Output (32 Ohms) : 1W (THD+N < 0.003%)
• Max Output (150 Ohms): 365 mW (THD+N <
0.003%)
• Max Output (600 Ohms): 92 mW (THD+N <
0.003%)
• Output Impedance: 0.096 ohms
• Crosstalk (15 ohms) : -65 dB
• Channel Balance (50% volume): 0.2 dB
• Dynamic Range (A-Weighted): > 120 dB
• Linearity Error: -90 dBFS 24/96 -0.1 dB
• USB Jitter Components: 11025Hz -112dB
• RCA Line out: 1V RMS
Audio formats
• USB: 24/96, 24/48
• Optical: 24/192, 24/96, 24/48, 24/44.1,
16/192, 16/96, 16/48, 16/44.1
Dimensions
• 4.25” W x 3.25” L x 1.25” H
• Weight: 8.5 oz.
* specifications subject to change
based on manufacturing updates.
