Maytag CS - COMMERCIAL DRYER OPERATING INSTRUCTIONS; SET-UP INSTRUCTIONS (CS ONLY)

COMMERCIAL DRYER
OPERATING INSTRUCTIONS
MAYI A!3
® C 0 M M E R C I A L
LEAVE THESE INSTRUCTIONS WITH THE OWNER
Printed in U.S.A. 6 3405580
SET-UP
INSTRUCTIONS -
CS ONLY
The following example is a step-by-step
procedure used to set the mechanism to
accumulate two time settings totaling 53
minutes of dry time (accumulative setting).
1. Remove the movable return stops from the
coin box.
3. Install the movable return stop in position "D".
,
Remove the time adjustment peg from
position "C" (as set in manufacturing) and
install in position "B". See charts for
additional information.
MOVABLE RETURN
STOP IN
POSITION "D"
TIME
ADJUSTMENT
PEG IN
POSITION "B"
