NON-ACCUMULATIVE
TIMER SETTING OPTIONS
(60 MINUTE TIMER)
Position on Index Wheel
Time Association With Each
Actuation of The Coin Slide
Movable
Return Stop
Not used
Not used
Not used
Not used
Not used
Time Adjustment
Peg Position
"A" Adj, peg not used
B
C
D
E
60
53
47
40
33
ACCUMULATIVE
TIMER SETTING OPTIONS
SINGLE CS MODEL - 60 MINUTES
Time
Peg Position
A
A
A*
A
A
A*
A
B*
B
C
A
B
C
ReturnStop
Position(S)
B
B&D
B&E
C
C&E
D
E
D
E
E
Not used
Not used
Not used
D Not used
E Not used
Recommended settings
Time
Time Total
Added
1st 2nd 3rd
20 40 - 60
20 13 27 60
20 20 20 60
27 33 - 60
27 13 20 60
33 27 - 60
40 20 - 60
26.5 26.5 - 53
33 20 - 53
27 20 - 47
(Timer will be one-cycle, 60
non-accumulative) 53
47
40
33
Note: Movable return stops cannot be placed in adjacent positions
because the lower ears will interfere. Actual time may very depending
on local voltage and Hz,
LOCKS AND KEYS
On CS & PS models the control service door
and lock are NOT provided with the dryer.
Keys and locks should be ordered from your
commercial distributor.
INSTALLING COIN BOX LOCK
Assemble the spring washer over the threaded
portion of the lock and insert into the coin box
opening. Place the hex nut over the end of the
shaft and thread it into the lock.
NOTE: Do not overtighten nuts as this will
collapse the spring washer and tension will be
lost. The spring washer is designed to provide
tension between the shoulder of the lock and
the coin box. The tension can be adjusted by
either tightening or loosening the hex nut.
Test the dryer by running through complete
cycle.
MN MODELS
(MANUAL NON-COIN)
Modification of control center is not necessary.
Test dryer through complete automatic cycle.
