Maytag MDG28PDCWW User Manual

Reverse Hinge
1. Use a small at-blade screwdriver to remove 2 plug strips
from the inner door. Slide the head of the screwdriver under
the plugs, being certain not to scratch the inner door surface.
Lift up.
2. Remove the 4 screws that attach to the inner door hinge and
move the hinge to the other side. Reinstall the 4 screws.
3. Reinstall plug strips on opposite side of the inner door.
4. Check for ngerprints on the glass. Clean glass if necessary.
5. Place the inner door assembly inside the outer door
assembly. To t correctly, the inner door assembly edge ts
completely inside the outer door assembly edge.
6. Reassemble the inner and outer door assemblies with the
6 screws.
Door swing can be changed from a right-side opening
to left-side opening, if desired.
Place a towel or soft cloth on top of the dryer or workspace
to prevent scratching the surface.
Remove the Door Assembly
1. Remove 3 of the 4 screws that hold the door hinge on the
front panel of the dryer. Partially loosen the remaining screw
with keyhole opening and lift the door off the screw.
2. Lay the door assembly on a previously prepared at surface
with the inside (inner door assembly) facing up.
3. Remove the 6 Phillips head screws to release the outer door
assembly from the inner door assembly, as indicated below.
See illustration. It is important that you remove only the 6
indicated screws.
4. Lift the inner door assembly off the outer door assembly.
5. Rotate outer door 180°.
22
Door hinge
A.
B.
A. Dryer front panel
B. Door assembly
Loosen
screw
with
keyhole
opening
REVERSING THE DOOR SWING

Maytag MDG28PDCWW Specifications

General

Type	front load
Color	white
Dryer Capactity	6.7 cu. ft.
Venting	vented
Control Panel	digital
Drying Rack	no
Sensor Dry Option	no
Steam	no
Wi-Fi	no
Voltage	120 volts
Current	15a

Weight and Dimensions

Depth	29 inch
Height	45 3/4" (leveling legs)
Width	27 inch
