44 PROGRAMMING MANUAL 516532 B PUBLICATION DATE 1 JUN 2007.DOC
T TEST SEQUENCE
 Display test and door lock test
 Sensor test
 Motor test
 Water fill and drain test
 BASIC Diagnostic Wash program
T Diagnostic Test Sequence
Test
N°
Info Explanation
1
Black display followed
by a Text display.
£ Door lock test (locks and unlocks 5 x the door)
£ Display test
***
None £ Sensor test (all wash machine sensors are
tested)
3
Reverse £ Wash speed (inverse direction high spin)
4
Stop
⇒ Standstill motor
5
Forward £ Wash speed (same direction high spin)
6
Distribution £ Distribution speed (same direction high spin)
7
Low spin £ Low spin speed (same direction high spin)
High spin £ High spin speed
(the drum is turning away from the soap box)
8
Stop £ Free run or controlled deceleration
20
I1 £ The machine takes water by inlet 1
21
Drain 1 £ The water is drained by drain valve 1
22
I2 £ The machine takes water by inlet 2
23
Drain 1 £ The water is drained by drain valve 1
24
I3 £ The machine takes water by inlet 3
25
Drain 1 £ The water is drained by drain valve 1
26
I4 £ The machine takes water by inlet 4
27
Drain 1 £ The water is drained by drain valve 1
28
I5 £ The machine takes water by inlet 5
29
Drain 1 £ The water is drained by drain valve 1
32
I6 £ The machine takes water by inlet 6
31
Drain 1 £ The water is drained by drain valve 1
50
Tumble
⇒ The tumble sequence
Unload
⇒ End of the Diagnostic Cycle
