516532 B PUBLICATION DATE 1 JUN 2007.DOC PROGRAMMING MANUAL 45
T BASIC Diagnostic Wash program
Sequence Supply Inlet
Top Front Top Front Top Front
Temp. Level Wash action Time R.P.M.
Wash Wash B - 3-4-5 2-3 104°F NL A=12“ R=3“ 6 min W
Step 1
Drain Drain - - - - - - - 30 sec D
Rinse 1 Rinse 1 - - 2-5-6 2 - NH A=12“ R=3“ 1.5 min W
Step 2
Spin Spin - - - - - - - 1 min L
Final Rinse Rinse 3 C - 1(+6) 1(2) - NL A=12“ R=3“ 2 min W
Step 3
Spin Spin - - - - - - - 4.5 min H
Slowdown - - - - - - - 1 min -
Tumble - - - - - - A=12“ R=3“ 30 sec W
Diagnostic Error messages :
• If the computer detects some problem during the Diagnostic Help Program, a diagnostic error message is
generated.
• Check also the Diagnostic Error Log List in the Service-menu.
• Check the error handling and explanation of the error messages.
