Data Label Information __________
Standard Label
When contacting Maytag, the information on the data label is
required to ensure proper service/parts assistance. The data label
is located at the upper right rear of the dryer behind the back
guard.
1. Model Number – This describes the style of dryer and type of
heat (gas, electric, or steam).
2. Serial Number – Allows the manufacturer to gather
information on your particular dryer.
3. Type of Heat – This describes the type of heat for your
particular dryer, gas (either natural gas or Propane gas),
electric, or steam.
4. Heat Input (For Gas Dryers) – This describes the heat input in
British thermal units per hour (Btu/hr) or kilowatts (kW).
5. Orice Size (For Gas Dryers) – Gives the number drill size
used.
6. Electric Service – This describes the voltage and current
rating for a particular model.
7. Gas Manifold Pressure (For Gas Dryers) – This describes the
manifold pressure taken at the gas valve tap.
SECHEUSES, VOL.2
INPUT(ENTREE) =
ORIFICE =
ORIFICE
MOD
SER
INPUT (0 TO 2,000 FT.)
(ENTREE (0 A` 610M))*
HEAT(CHALEUR) TYPE
120V/60HZ/1PH/2W 16A
MANIFOLD PRESSURE(PRESSION A LA TUBULURE D`ALIAMENTATION)
USE WITH(UTILISER AVEC DU ) GAS(GAZ)
CLOTHES DRYERS, VOL.II
ANSI Z21.5.2-2013 CSA 7.2-2013
MIN. SUPPLY PRESSURE(PRESSION) MAX. SUPPLY PRESSURE(PRESSION)
*FOR CANADIAN INSTALLATIONS WITH ELEVATIONS BETWEEN 2,000 AND 4,500 FT.
(POUR LES INSTALLATIONS CANADIENNES AVEC DES ELEVATIONS ENTRE 610 A` 1372M)
Assembled in (Assemble aux) USA
Whirlpool Corporaon TEL: (269) 923-3000
88 Currant Road FAX: (508) 678-9447
Fall River, MA 02720-4781 mdl-service@whirlpool.com
WWW.WHIRLPOOL.COM
"NRTL"
3
MAN8402
7
6
5
4
1
2
