Maytag MLG33 Service Procedures Guide

4 Maytag Co. 450266-2
Part Locations and Removal
UPPER FRONT PANEL REMOVAL:
Remove the four screws located just above the top
loading door. Tilt the bottom of the panel out and lift
the panel up and away from the dryer.
LOWER FRONT PANEL REMOVAL:
Remove the lint drawer. Remove the four screws
located just below the loading door. Tilt the top of
the panel out and lift the panel up and away from the
dryer.
TOP COVER REMOVAL:
First remove the back guard, the four screws holding
top cover. Next pull top cover toward the rear of the
dryer and lift up.
MIDDLE PANEL REMOVAL:
Remove the four screws along bottom of panel.
Next, remove four screws along top of panel.
Tilt the top of the panel out, disconnect electrical
connection to computer panel, lift panel and unhook
support brackets.
