19
Reverse the strike
1. Remove the door strike from the dryer door opening.
2. Re
move the cosmetic cover opposite the door strike.
A
B
A. Door strike
B. Cosmetic cover
3. Reinstall the door strike and cosmetic cover on the opposite side of the dryer door
opening from where they were removed.
NOTE: Door strike and plugs must be on the same side of the dryer door opening.
Reinstall the door
1. Re
move the 4 screws and 2 hinges from the dryer door.
2. Replace the 4 screws in the same holes.
Screw & hinge
locations
3. Remove the 4 screws from the opposite side of the door.
Screw locatons
4. Install the 2 hinges to the front panel of the dryer using 4 screws. Use the non-slotted side
to attach the hinge to the front panel.
