7-8
In Case of an Emergency
Flat Tire
Form No. 8Q94-EA-02G
▼
Removing a Flat Tire
1. Pry off the wheel cover with the
beveled end of the lug wrench.
2. Loosen the lug nuts by turning them
counterclockwise one turn each, but
don’t remove any until the tire has been
raised off the ground.
3. Place the jack under the jacking
position closest to the tire being
changed.
NOTE
Force the end of the wrench firmly
between wheel and cover, or removal
will be difficult.
Align the notch on the wheel cover
with the valve stem when installing it.
Damage could occur during
installation if the wheel cover is not
properly aligned.
Wheel cover
Lug wrench
CAUTION
Tire valve
Notch
Jacking position
