8-22
Maintenance and Care
Owner Maintenance
Form No. 8Q94-EA-02G
4. Carefully insert the new blade rubber.
Then install the blade assembly in the
reverse older of removal.
▼
Replacing Rear Window Wiper
Blade (Hatchback)
When the wiper no longer cleans well, the
blade is probably worn or cracked.
Replace it.
1. Raise the wiper arm and turn the blade
assembly to expose the plastic locking
clip.
Compress the clip and slide the
assembly downward; then lift it off the
arm.
2. Pull down the blade rubber and slide it
out of the blade holder.
NOTE
Install the blade so that the tabs are
toward the bottom of the wiper arm.
To prevent damage to the wiper arm
and other components, don’t move the
wiper by hand.
Tab
CAUTION
To prevent damage to the rear window,
don’t let the wiper arm fall on it.
Push
Plastic locking clip
To Next Page
