FUEL GAUGE
TACHOMETER SPEEDOMETER
DASHBOARD
ILLUMINATION
1
ODOMETER/
TRIP METER/SELECTOR
2
GLOSSARY OF WARNING AND INDICATOR LIGHTS
NOTE: SeeOwner’sManualformoredetailsandexplanations.
A/T SHIFT
INDICATOR
Traction Control System
(TCS)/Dynamic Stability
Control (DSC)
On:TCS/DSCmalfunction
Flashing:TCS/DSCoperating
Seat Belt
Unbuckled/Malfunction
Cruise On (Amber)/
Cruise Set (Green)
Headlight High Beams On
Automatic Transmission
Malfunction
A/T Shift Position Indicator
Door/Liftgate Ajar
Air Bag/Front Seat Belt
Pretensioner System
Malfunction
Low Engine Oil Pressure
Charging System
Malfunction
Security Indicator Light
Key Warning RED
Advancedkeynotdetected
oradvancedkeybatteryisdead.
Key Detected (engine
ready to start) GREEN
On:Advancedkeydetected;engine
isreadytostart.
Flashing:Advancedkeybatteryislow.
Brake Warning Light
Parkingbrakeon/lowbrake
uid/malfunction
Electronic Steering Lock
Dynamic Stability Control
(DSC)/Traction Control System
(TCS) Off Indicator Light
DSCOFFswitchedpushedand
TCS/DSCturnedoff.
DSC
OFF
Adaptive Front Lighting
System (AFS) OFF
Check Fuel Cap
Lights On (Exterior)
Anti-lock Brake System (ABS)
Malfunction
High Engine Coolant
Temperature
Flasheswhenenginestartstorunhot
andonwhenengineisrunninghot.
Power Steering Malfunction
Check Engine Light
Tire Pressure Monitoring
System (TPMS
) Warning Light
On:LowTirePressure
Flashing:TPMSMalfunction
NOTE:
Thetirepressureshouldbeset
whentiresarecold.Largechangesin
ambienttemperaturesoraltitudewill
causetirepressurechangeandmay
causeTPMSwarninglighttoturnon.
Low Fuel Level
Turn Signals/Hazard
Warning Indicator Lights
AFS
OFF
1
•Rotatetheknobtoadjustthebrightnessoftheinstrumentclusterandotherdashboardilluminations.
Vehicles with Multi-Information Display:
 •Tocancelthedimmerswitchpushtheknob.
 •Withtheheadlightson,theilluminationoftheinstrumentclusterandinformationdisplaydims.
NOTE:Iftheinstrumentclusterandotherdashboardilluminationsdonotdimwhenturningonthe
 headlights,pushtheknob.
Instrument Cluster
2
•Pushtotogglebetweenodometerandtripodometer(A&B).
 •Whenatripmeterisselected,pushandholdtoresettozero.
DSC OFF
