Automatic Climate Control
14
Manual Climate Control
Driver Temperature
Control Dial
1 PushAUTOONto
turntheAutomatic
AirConditioning
systemON.
2 Rotatedialtodesired
airtemperature
(showninInformation
Displayabove).
Fan Control Dial
•Rotatethedialto
selectthedesired
fanspeed.
• PushOFFtoturn
climatecontrol
systemoff.
Note:
Donot
rotate dialin
AUTO ONmode.
Pushtodefrost
thewindshield.
Pushtodefrost
therearwindow.
NOTE: (AppliestoManualandAutomaticClimateControlSystems)
Withdefrosterandoorventsorwindshielddefrostermode,thesystemturnson
theA/CcompressorandselectstheFRESHAIRmode.Thishelpsdefrostthe
windowsmoreefcientlybydehumidifyingtheair.TheA/Ccompressorwillalways
beonindefrostermode,butthedefroster(andoor)willdeliverwarmairwhenthe
temperaturedialissettoawarmertemperatureandtheenginewarmsup.
Temperature
Control Dial
Rotatethedialfor
temperaturecontrol.
NOTE:
Whenset
toMAXA/Cwith
dashboardventsor
dashboardandoor
vents,theA/Cwill
turnon,and
recirculatedairwill
beselectedfor
maximumcooling.
Fan Control Dial
Rotatethedialtoset
desiredfanspeed(1-4).
 Pushtodefrostthe
rearwindow.
 Pushtomanually
turnairconditioning 
onoroff.
 Pushtorecirculate
cabinairtoreduce
outsideodorsand
improvecooling
(indicatoron)or
receivefreshair
(indicatoroff).
Passenger Temperature
Control Dial
PushtoturnDUALmode
ON/OFF.
• WithDUALmodeON
(indicatoron),rotatethe
dialtosetpassengerside
temperatureseparate
fromthedriver’sside
(shownintheInformation
Displayabove).
• WithDUALmodeOFF
(indicatoroff),driver
controlsthetemperature
settingonbothsides.
Mode Selector Dial
Rotatethedialtoselect
airowmode.
  Dashboard
vents
  Dashboardand
oorvents
  Floorvents
  Defrosterand
oorvents
  Windshield
defroster
INFORMATION DISPLAY
Pushtoselect
thefollowing
airowmode:
Automaticclimate
controlwillallowyou
tomaintainindividual
presetcabin
temperaturesforthe
driverandpassenger
whenDUALmode
isselected.
Pushtorecirculate
cabinairtoreduce
outsideodorsand
improvecooling
(indicatoron)orreceive 
freshair(indicatoroff).
Pushtomanuallyturn
airconditioningon
oroff.
  Dashboard
vents
  Dashboard
andoorvents
  Floorvents
  Defrosterand
oorvents
  Windshield
defroster
