Maintenance and Care
Owner Maintenance
4. Move the air cleaner cover and create a
space large enough to work in.
5. Disconnect the connector from the unit
by pressing the tab on the connector
with your nger and pulling the
connector downward.
6. Turn the socket and bulb assembly
to remove it. Carefully remove the
bulb from its socket in the reector by
gently pulling it straight backward out
of the socket.
7. Install the new bulb in the reverse order
of the removal procedure.
(Right side)
1. Make sure the ignition is switched off,
and the headlight switch is off.
2. Lift the hood.
3. Disconnect the clip.
Clip
