Mazda 6 2017 - Page 564

9 – 12
Specications
Personalization Features
Item Feature
Factory
Setting
Available
Settings
Settings
Change
Method
Blind Spot
Monitoring (BSM)
(page 4-94)
The system can be changed so that Blind
Spot Monitoring (BSM) does not operate.
*1
On On/Off A —
Warning beep volume
*2
High
High/
Low/
Off
A —
Distance
Recognition Support
System (DRSS)
(page 4-107)
The system can be changed so that
Distance Recognition Support System
(DRSS) does not operate.
*1
On On/Off A —
The distance at which the vehicle ahead
and your vehicle indicated in the display
ashes in white can be changed.
Near
Far/Medium/
Near
A —
Trafc Sign
Recognition System
(TSR)
*3
(page
4-100)
The Trafc Sign Recognition System
(TSR) can be set to inoperable.
*1
On On/Off A —
The warning pattern of the excessive speed
warning can be changed.
Off
Off/
Warning display
only/
Warning display
warning
sound
A —
The activation timing for the excessive
speed warning can be changed.
0 0/ 5/ 10
A —
Vehicle
Door locks (page
3-16)
Operation condition of auto lock/unlock
function
Lock:
Driving,
Unlock: IGN
Off
Off/
Lock When
Driving/
Lock: Driving,
Unlock: IGN
Off/
Lock When
Shifting Out
Of P/
Lock: Shift
From P,
Unlock: In P/
Lock: Driving,
Unlock: In P
A D
Keyless entry
system (page
3-3)
Method for unlocking door using
transmitter
Once:
Driver's,
Twice: All
Doors
Touch Once:
All Doors/
Once: Driver's,
Twice: All
Doors
A E
Time for locking door automatically 60 seconds
90 seconds/
60 seconds/
30 seconds
A —
