Removing the luggage compartment
cover
This cover can be removed for more
room.
1. Remove the straps from the hooks.
2. Press the luggage compartment
cover upward from near the pins
and remove the luggage
compartment cover from the pins.
1. Pin
3. Lift the front end of the luggage
compartment cover and remove it.
Before Driving
Doors and Locks
3-29
CX30_8JP5-EA20K_Edition1_new 2020-7-22 15:50:09
