Mazda CX-30 - Instrument Cluster and Display

Instrument Cluster and
Display
▼
Instrument Cluster and Display
① Instrument Cluster.......... page 4-12
② Active Driving Display..... page 4-28
Instrument Cluster
▼
Instrument Cluster
① Tachometer.................... page 4-13
② Multi-information Display...............
..................................... page 4-14
③ Engine Coolant Temperature
Gauge............................page 4-16
④ Fuel Gauge..................... page 4-17
⑤ Dashboard Illumination
Switch............................page 4-18
⑥ Speedometer..................page 4-12
⑦ TRIP Switch.................... page 4-16
▼
Speedometer
The speedometer indicates the speed
of the vehicle.
When Driving
Instrument Cluster and Display
4-12
