The system may have a malfunction if a message indicating a system malfunction is
displayed. Have your vehicle inspected by an Authorized Mazda Dealer.

A message may be displayed even when the ambient temperature is extremely
cold, or mud, ice, or snow adheres to the sensor area. Remove any foreign matter
from the sensor area.
▼
Sensor Detection Range
The sensors detect obstructions within the following range.
1. Front ultrasonic sensor detection range
2. Rear corner/Rear side ultrasonic sensor detection range
3. Rear ultrasonic sensor detection range
4. Front corner ultrasonic sensor detection range
A About 55.0 cm (About 21.6 in)
B About 150 cm (About 59.0 in)
C About 100 cm (About 39.3 in)
Viewing distance display
Display Distance between vehicle and obstruction
Without 360° view
monitor
With 360° view moni-
tor
Front ultrasonic sensor
*
/
Front corner ultrasonic
sensor
*
Rear ultrasonic sensor/
Rear corner ultrasonic
sensor/Rear side ultra-
sonic sensor
*
Green
Front ultrasonic sensor:
Approx. 100―60.0 cm
(39.3―23.6 in)
Rear ultrasonic sensor:
Approx. 150―60.0 cm
(59.0―23.6 in)
When Driving
Parking Sensor System
4-234
*Some models.
