3. Disconnect the bulb by pulling it out.
4. Install the new bulb in the reverse
order of the removal procedure.
▼
Replacing Interior Light Bulbs
The interior lights have either LEDs or
normal bulbs.
LED type
Front overhead lights/Front map lights
Centre map lights
Rear overhead light
The LED bulb cannot be replaced as a
single unit because it is an integrated unit.
The LED bulb has to be replaced with the
unit. We recommend an Authorised Mazda
Repairer if the replacement is necessary.
Bulb type
Front overhead lighst/Front map lights,
Centre map lights, Rear overhead light,
Vanity mirror lights
1. Wrap a flathead screwdriver with a
soft cloth to prevent damage to the
lens, and then remove the lens by
carefully prying on the edge of the lens
with a flathead screwdriver.
2. Disconnect the bulb by pulling it out.
Front overhead lights/Front map
lights
Maintenance and Care
Owner Maintenance
6-39
