Centre map lights
Rear overhead light
Edge
Vanity mirror lights
Driver’s seat
Passenger’s seat
3. Install the new bulb in the reverse
order of the removal procedure.
Luggage compartment light
1. Wrap a small flathead screwdriver with
a soft cloth to prevent damage to the
lens and remove the lens unit by
carefully prying on the edge of the lens
unit with the flathead screwdriver.
Maintenance and Care
Owner Maintenance
6-40
