5. Turn the socket and bulb assembly to
remove it. Carefully remo ve the bulb
from its socket in the reflector by
gently pulling it straight backward out
of the socket.
6. Install the new bulb in the reverse order
of the removal procedure.
NOTE
l
To replace the bulb, contact an Authorized
Mazda Dealer
l
If the halogen bulb is accidentally touched,
it should be cleaned with rubbing alcohol
before being used.
l
Use the protective cover and carton of the
replacement bulb to dispose of the old bulb
promptly out of the reach of children.
Low-beam bulbs
1. Make sure the igni tion is switched off,
and the headlight switch is off.
2. Lift the hood.
3. (Right side)
Remove the attachment bolts and the
coolant reservoir before replacing the
light bulb.
4. Turn the cover counterclockwise and
remove it.
8-42
Maintenance and Care
Owner Maintenance
