Meters and Gauges
Speedometer ...................................................................................................... page 5-39
Odometer, Trip Meter and Trip Meter Select or .................................................. page 5-39
Tachometer ........................................................................................................ page 5-40
Fuel Gauge ................................................................................ ........................ page 5-40
Instrument Panel Illumination ........................................................................... page 5-41
NOTE
(Black-out meter)
When the ignition is switched ON, the instrument panel gauges illuminate.
