Vent Operation
qAdjusting the Vents
Directing airflow
Side Vents
To adjust the direction of airflow, open the
vents and rotate them left and right.
Push
Centre Vents
To adjust the direction of airflow, move
the adjustment knob.
Knob Dial
Close
Open
6-4
Interior Comfort
Air-Conditioning System
